Product Details:
|
| Resolution: | 1920(RGB)×1080 (FHD) | Panel Type: | A-Si TFT-LCD |
|---|---|---|---|
| Panel Model: | G156HAN01.0 | Pixel Density: | 141 PPI |
| Size: | 15.6 Inch | ||
| High Light: | auo display panel,auo lcd display |
||
15.6 inch G156HAN01.0 LCD Display Panel Antiglare, Hard coating (3H) 1920×1080 Resolution
Here comes our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| X139BLB01.0 | AUO | 1.39" | 400×400 |
| H381DLN01.0 | AUO | 3.8" | 1080×1200 |
| H497TLB01.4 | AUO | 5.0" | 720×1280 |
| H163QLN01.0 | AUO | 1.63" | 320×320 |
| H139BLN01.2 | AUO | 1.39" | 400×400 |
| H500TLB01.0 | AUO | 5.0" | 720×1280 |
| X546DLB01.0 | AUO | 5.5" | 1080×1920 |
| H546DLB01.1 | AUO | 5.5" | 1080×1920 |
Pls contact to us for more stock information: salespm@nselectronic.com.hk
General Features :
| Panel Model | G156HAN01.0 |
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,15.6 inch, 1920×1080 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | AHVA, Normally Black, Transmissive |
| Active Area | 344.16×193.59 mm |
| Outline | 363.8×215.9×9.8 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.2M (6-bit + FRC) , CIE1931 72% |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLED Embedded (LED Driver) |
| Signal Interface | eDP (2 Lanes) , 40 pins |
| Input Voltage | 3.3V (Typ.) |
Company strength:
Our guarantee:
(1) Our all LCD screen will be strictly tested pcs by pcs and shipped with professional & safe package.
(2) We have 12 months warranty for each LCD display, depend on the different items.
(3) We will do our best to solve any possible problem of our LCD panels for your after sale. Please contact with us if any needs.
